Technical Specifications | |
Imperial Metric | Dimension & weight |
Dimension & weight | |
Height | 239 mm |
Length | 387 mm |
Output size | 1" |
Width | 74.5 mm |
Weight | 10.8 lb |
Certifications, standards & directives | |
CCC certified | No |
CMIIT ID | 2018AJ0238 |
EAC certified | Yes |
EU Standard | EN 18031-1:2024||EN 300 328 V2.2.2||EN 300 |
440 V2.1.1||EN 301 489-1 V2.1.1||EN 301 489-17 | |
V3.1.1||EN 55014-1:2017||EN 55014-2:2015||EN | |
61000-6-2:2019||EN 61000-6-3:2007+A1:2011||EN 61000-6- | |
4:2007+A1:2011||EN 62841-1:2015 + AC:2015 + | |
A11:2022||EN 62841-2-2:2014 + AC:2015 | |
EU Legislation | (EU) 2022/30||2006/42/EC (MD)||2011/65/EU |
(RoHS)||2014/53/EU (RED)||2015/863/EU | |
(RoHS amendment) | |
ETL control number | 3008099 |
ETL listed | Yes |
ETL text | 6 - 62841-2-2 |
EU SAR value | 0.49 W/kg |
FCC ID | PVH0965 |
IC ID | 5325A-0965 |
KC certified | Yes |
KC ID | R-R-50A-SRBHA |
UK Regulations | S.I. 2008/1597||S.I. 2012/3032||S.I. 2017/1206 |
UK Standard | S.I. 2008/1597||S.I. 2012/3032||S.I. 2017/1206 |
489-1 V2.1.1||EN 301 489-17 V3.1.1||EN 55014- | |
1:2017||EN 55014-2:2015||EN 61000-6- | |
2:2019||EN 61000-6-3:2007+A1:2011||EN | |
61000-6-4:2007+A1:2011||EN 62841-1:2015 + | |
AC:2015 + A11:2022||EN 62841-2-2:2014 + AC:2015 | |
WEEE | 5 - Small equipment <50cm |
Torque | |
Torque range max | 553 ft-lb |
Torque range min | 166 ft-lb |
Design & Functions | |
Model type | Pistol |
Output type | Square, Male |
SCIP | 68c2f2d6-c770-45dc-b4e1-5cfc88785683 |
Shut-off system | Transducer |
Tool family | SRB |
Power | |
Motor power | 1500 W |
Motor voltage type | d.c. |
Motor voltage | 36 V |
Battery information | |
Battery | Li-Io 36 V |
Type of battery | 1 Li-ion |
Weight incl. Battery | 12.6 lb |
Noise & vibrations | |
Sound pressure | 54 dB(A) |
Sound standard | ISO15744 |
Vibration standard | ISO28927-2 |
Vibration uncertainty | <2.5 m/s² |
Speed | |
Speed range max | 46 r/min |
Design | |
Clutch type | Twin hammer |
