Model |
Drive Size (in) |
Torque Range ft-lb (Nm) |
Stall Torque ft-lb (Nm) |
Side to Center in (mm) |
Head Height, in (mm) |
Weight lbs (kg) |
Free Speed (rpm) |
Length in (mm) |
|---|---|---|---|---|---|---|---|---|
|
QA8AALD040NP35S06 |
3/8 |
30 (40) |
38.3 (52) |
0.69 (18) |
1.71 (43.5) |
4.98 (2.26) |
570 |
17.8 (453) |
|
QA8AALD040NP35S08 |
1/2 |
30 (40) |
38.3 (52) |
0.69 (18) |
1.71 (43.5) |
5.00 (2.27) |
570 |
17.8 (453) |
|
QA8AALD055NP35S08 |
1/2 |
41 (55) |
50.1 (68) |
0.69 (18) |
1.71 (43.5) |
5.00 (2.27) |
425 |
17.8 (453) |
|
QA8AALD070NP43S08 |
1/2 |
52 (70) |
63.4 (86) |
0.85 (22) |
1.76 (44.7) |
5.00 (2.27) |
320 |
17.5 (445) |
|
QA8AALD090NP43S08 |
1/2 |
66 (90) |
79.6 (108) |
0.85 (22) |
1.76 (44.7) |
5.00 (2.27) |
255 |
17.5 (445) |
|
QA8AALD115NP48S08 |
1/2 |
85 (115) |
91.4 (124) |
0.97 (25) |
1.97 (50) |
5.75 (2.61) |
200 |
17.8 (452) |
|
QA8AALD150NP48S08 |
1/2 |
111 (150) |
121.7 (165) |
0.97 (25) |
1.97 (50) |
6.48 (2.94) |
145 |
19.2 (489) |
|
QA8AALD200NF56S12 |
3/4 |
148 (200) |
157.1 (213) |
1.19 (30) |
2.09 (53.2) |
8.47 (3.84) |
110 |
20 (508) |
|
QA8AALD225NF56S12 |
3/4 |
166 (225) |
202.1 (274) |
1.19 (30) |
2.09 (53.2) |
8.47 (3.84) |
90 |
20 (508) |
